New Leica BLK360 2G

Name: New Leica BLK360 2G
Brand: Leica
SKU: sku-147
Price: 12500 USD
Availability: InStock
Rating: 5 (28 reviews)

We are selling Brand New Leica BLK360 Imaging Laser Scanner includes with all accessories and comes with Leica Cyclone REGISTER 360 (BLK Edition), BLK360 G2 is one of the smallest laser scanners on the market today while packing HUGE power!

$12500

Description

We are selling Brand New Leica BLK360 G2 Imaging Laser Scanner includes with all accessories and comes with Leica Cyclone REGISTER 360 (BLK Edition). 3D laser scanner with integrated high-speed HDR spherical camera system and visual inertial system (VIS) for real-time pre-registration.

The all-new Leica BLK360 G2 Laser Scanner breaks open the possibilities of reality capture. With unprecedented, best-in-class scanning speed, the BLK360 makes you faster. Blaze through job sites with rapid scanning that doesn’t compromise on quality. Your work is faster, your job is easier, and you get the data you need right away.

Leica BLK360 G2 Laser Scanner Includes:

(1X) Leica BLK360 G2 Laser Scanner
(1X) Leica GVP739 Transportation Case
(3X) Leica GEB825 Battery
(1X) Leica GKL825 Multi-charger
(1X) Leica GEV278 USB Cable
(1X) Leica BLK Cleaning Cloth
(1X) Leica BLK360 G2 Quick Guide
(1X) Leica BLK360 G2 USB Documentation Card
Download: New-Leica-BLK360-2G-Scanner
Download: Leica BLK360 Quick Start Guide

leica-BLK360-G2-Laser-scanner

ULTRA-FAST SCANNING
A supercharged next-gen imaging laser scanner, the BLK360 from G2 captures a full scan with spherical images in only twenty seconds - over five times faster than the BLK360 G1.

COMPLETE DATA CAPTURE
With fast and agile in-field workflows, along with live feedback on your mobile device, you can be absolutely sure you’ve captured everything you need, and even more. And VIS technology automatically combines your scans to speed up your workflow and help you make sure your datasets are complete.

CREATE IMMERSIVE DELIVERABLES

BLK360 data is highly valuable for so many uses—from AEC to VFX and VR—and you can easily transfer and work with it in your software ecosystem to create immersive and highly accurate deliverables and experiences.
With its unprecedented speed, the new BLK360 is perfect for use in areas such as real estate, architecture, engineering, and construction, media and entertainment, surveying, historical preservation, and so much more.
The award-winning BLK360 G1 is still fast, portable, and very easy to use. It will remain available and might be the perfect fit for your reality capture workflow.

BLK LIVE APP
For quick scanner operation and basic scan export, users can get started with BLK Live for iOS and Android. This free software enables you to control your BLK360 in the field, view scan data from your smartphone or tablet, and export unregistered .e57 point cloud files.

BLK360-G2-Handled-scanner

SPECIFICATIONS:

Design & Physical Characteristics:

Corps Black anodized aluminum
Dimensions Height: 155 mm Diameter: 80 mm
Weight 0.75 kg (0.85 kg with battery)
Transportation case Leica GVP739
Tripod mount Quick-release adapter

Management:

Off-line control One button
Mobile devices BLK Live app for iOS and Android smartphones Leica Cyclone FIELD360 app for iOS and Android smartphones and tablets
Wireless Connection Integrated WLAN radio (802.11 b/g/n)
Internal storage Up to 1500 stations
Orientation of the device Normal or inverted

Nutrition:

Battery type Leica GEB825 internal rechargeable Li-Ion battery
Capacity Up to 70 stations on a single battery

Scan:

Rangefinder High-speed pulse with Waveform Digitizing (WFD) technology.
Laser radiation class >1 (in accordance with IEC 60825-1:2014).
Laser wavelength 830 nm.
Sight 360° (horizontal) / 270° (vertical).
Range (at 78% albedo) from 0.5 m to 45 m.
Measurement speed up to 680000 points/s.
Measurement modes 4 user-selectable scan density settings: 6/12/25/50 m at a distance of 10 m.

Image Capture:

Camera system The 4-camera 13 Mpix system captures 104 Mpix raw data for a calibrated 360° x 270° spherical image.
Speed < 8 s for full spherical LDR panorama in all light conditions; < 20 seconds for a full spherical panorama of 5-stop HDR in all light conditions.
Image Capture Modele: LDR with auto exposure; 5-stop HDR; Off scan only.

Performance:

Data collection < 20 s for full scanning with a density of 50 mm by 10 m and capturing spherical LDR panoramas, with automatic tilt measurement
3D point accuracy (at 78% albedo) 4 mm @ 10 m
Real-time pre-registration Automatic alignment of point clouds, based on real-time tracking of the scanner's movement between stations using the Visual Inertial System (VIS), an inertial system module with the additional use of camera images.

Environmental conditions:

Destination For internal and external use
Operating temperature 0° C to + 40° C
Degree of protection against dust and humidity IP54 (IEC 60529)

Data processing:

Data transfer Wi-Fi b USB 3.0
Office software Leica Cyclone REGISTER 360 and Cyclone REGISTER 360 (BLK Edition)
Cloud-based software HxDR Digital Reality: A cloud-based digital reality platform
